TECHNICAL SPECIFICATION

APPLICATION

• Can be installed in cooling channels of Ø2 mm or larger

• Available in screw type, O-ring type, and packing type connections

• Compatible with Ø4 tube couplings or taper pipe threads for secure fitting

• Head Material: Brass (Bs)

• Outer Tube: SUS304

• Inner Tube: SUS304

• O-ring (Tube Coupler): FKM-70(4-D) – Heat resistance up to 200°C

• Maximum Working Pressure: 1.5 MPa

• Maximum Working Temperature: 180°C

• Ideal for die casting moulds requiring focused and efficient spot cooling

• Suitable for installation in narrow core pins where standard cooling channels cannot be applied

• Jet Cooler with O-ring allows “one-touch” connection using Ø4 tube, with installation hole diameters of Ø6, Ø8, and Ø10

Advantages

• Customizable revolver position for flexible installation.

• Equipped with a quick coupler system instead of hex bolts, enabling faster and easier maintenance.
