TECHNICAL SPECIFICATION

APPLICATION

• Core Pins Cooled: 20 / 40 / 60 / 100 Nos

• Cooling Channels: 2 / 4 / 6 Nos

• Touch Screen HMI: Mitsubishi 7"

• Data Storage & Transfer (Mold / Production): 16 / 200

• Foot Print (L×W): 1.0 × 0.65 m

• Standard / Certification: CE

• Die-casting systems requiring precise and reliable core cooling

• Minimization of shrinkage porosity in thin-walled or complex castings

• Suitable for automotive, industrial, and consumer die-cast components

• Plug-and-play operation with minimal maintenance and international standard compliance

FEATURES

• Flow Rate Measurement

• Air & Water Pressure Measurement

• Core Pin Breakage Detection

• Curve per Channel Display

• Error Diagnostic & Recording

• Phase Loss Protection Devices

• Phase Reversal Protection

• Earth Leakage Protection & Detection

• Residual Voltage, Earth Fault & Circuit Break Protection

• Over / Under Voltage Protection
